Unload manually #04506 (MMU)

Este artículo está también disponible en los siguientes idiomas:

What happened?

Implausible SuperFINDA reading. This error happens when a filament is detected by the SuperFINDA sensor although the MMU doesn’t have a record of any filament being loaded. It is unsure of which position the filament is loaded in so it can’t perform the unload automatically.

This usually happens due to a malfunctioning or improperly calibrated SuperFINDA sensor.

Another potential cause could be if the filament was inserted into the selector manually, bypassing the menu/buttons, or if the printer was restarted during a load/unload operation before it was completed.

How to fix it?

• Verify there is no filament in Selector and SuperFINDA sensor isn’t detecting a filament.
• If there is a filament loaded, unload it manually or clear the sensors from anything that caused it to trigger.
• If filament is loaded, unload it manually or clear any obstructions triggering the SuperFINDA sensor.
• Verify the proper superFINDA calibration.
• Use only the menu on the printer to load or unload a filament during regular use.
